The compact, fast and efficient Fanuc M-1iA/0.5SL is ideal for order picking, part transfer, assembly, and more. With 4 axes and a payload of 1kg, the M1iA/0.5SL works with small items while taking up minimal space. The M 1iA/0.5SL comes equipped with the advanced R-30iB controller variations and has a reach of 420mm.

Robots.com also offers used M-1iA/0.5SL robots. Their experts work hard to refurbish M-1iA/0.5SL robots.

Both the new and used Fanuc M-1iA/0.5SL have a variety of mounting options to meet a number of tasks that need the 4-axis motion with the great 420 mm reach and +/- 0.03 mm repeatability the M-1iA/0.5SL offers.

Specs

Reach
420 mm
Axes
4
Repeatability
0.03 mm
Mass
17 kg
Structure
Delta, Parallel Link
Mounting
Shelf

Motion Speed

J1
3000 °/s (52.36 rad/s)
J2
3000 °/s (52.36 rad/s)
J3
3000 °/s (52.36 rad/s)
J4
3000 °/s (52.36 rad/s)

Motion Range

J1
±420°
J2
±420°
J3
±150°
J4
±720°
