Motoman HP200T
Contact us:
Reach
2416 mm
Axes
6
Reach
2416 mm
Axes
6
Details
The Motoman HP200T is the ceiling-mounted version of the HP200 NX100.
Offering the same reliabilty and performance as the standard Motoman HP200, this model requires virtually no floorspace. The HP200T NX 100 can be mounted with a stationary positioner or on a gantry track for ultimate mobility.
The used Motoman HP200T is also available for sale through Robots.com. Robots.com representatives put all of their refurbished robots through an excellent reconditioning process that brings them back to like-new condition.
Specs
Reach
2416 mm
Axes
6
Repeatability
0.2 mm
Mass
1150 kg
Structure
Articulated
Mounting
Inverted
Motion Speed
J1
95 °/s (1.66 rad/s)
J2
85 °/s (1.48 rad/s)
J3
95 °/s (1.66 rad/s)
J4
115 °/s (2.01 rad/s)
J5
110 °/s (1.92 rad/s)
J6
190 °/s (3.32 rad/s)
Motion Range
J1
±180°
J2
±50°
J3
+220° - 125°
J4
±360°
J5
±125°
J6
±360°
