Motoman HP6RS
Contact us:
Reach
1147 mm
Axes
6
Applications
Reach
1147 mm
Axes
6
Applications
Details
The Motoman HP6RS is the short-arm, shelf mount variation. The Motoman HP6RS NX100 robot allows a larger work area because it has the ability to reach under and behind the robot body.
Robots.com experts also take pride in their refurbished robots to include the used Motoman HP6RS. The used HP6RS provides owners with the same benefits of a new one, as it has undergone a complete reconditioning process, bringing it back to like-new condition.
Specs
Reach
1147 mm
Axes
6
Repeatability
0.08 mm
Mass
0 kg
Structure
Articulated
Mounting
Floor, Inverted, Angle
Motion Speed
J1
180 °/s (3.14 rad/s)
J2
220 °/s (3.84 rad/s)
J3
220 °/s (3.84 rad/s)
J4
340 °/s (5.93 rad/s)
J5
340 °/s (5.93 rad/s)
J6
520 °/s (9.08 rad/s)
Motion Range
J1
+135° - 120°
J2
+90° - 130°
J3
+94° - 185°
J4
±180°
J5
±135°
J6
±360°
