Being rugged and versatile, the Motoman K30 will be a nice addition to your factory automation line. There are also used Motoman K30 robots available at Robots.com. Robots.com experts take pride in their refurbishment process and provide like-new used K30 robots.

The Motoman K30 has six axes of motion, allowing for a variety of arc welding, material handling, and process applications. Also, the K30 has a cycloidal wrist design and is fully functional with the MRC controller. An optional shelf mount version is also available. This model is also known as a Motoman K30SB.

The Motoman K30WS features the optional extended reach of 1971 mm. The K30 can use either an ERC or MRC controller.

Specs

Reach
1787 mm
Axes
6
Repeatability
0.2 mm
Mass
600 kg
Structure
Articulated
Mounting
Floor, Inverted, Angle

Motion Speed

J1
120 °/s (2.09 rad/s)
J2
120 °/s (2.09 rad/s)
J3
120 °/s (2.09 rad/s)
J4
200 °/s (3.49 rad/s)
J5
200 °/s (3.49 rad/s)
J6
300 °/s (5.24 rad/s)

Motion Range

J1
±300°
J2
±240°
J3
±260°
J4
±450°
J5
±270°
J6
±700°
