Motoman PX2050

Motoman

Request a Quote 1/4

Contact us:
Reach
Reach
2035 mm
Axes
Axes
6

Details

The Motoman PX2050 is a painting robot with Class 1, Division 1 approval in hazardous environments. The PX2050 XRC provides versatility and superior performance in standard industrial and automotive coating applications. The compact design of the highly flexible, six-axis PX2050 robot makes it easy to mount on the floor, wall, or ceiling.

The used Motoman PX2050 robot is also available for sale. The used PX2050 has undergone a very meticulous reconditioning process by the experts at Robots.com, bringing it back to like-new condition. This is a great way to save costs.

The flexibility of the new and used PX2050 goes beyond its 2035 mm horizontal reach, 10 kg payload, and 6-axis build. Its compact body allows for floor, wall and ceiling mounting. The used PX2050 also comes with two different specialized wrist types, the Lemma and three-roll which is ideal for painting contoured parts such as car bodies and interior/exterior surfaces and the Lemma, which is well-suited for painting horizontal and vertical planes.

Automate your painting, coating, and spraying application with the new or used Motoman PX2050 robot. This powerful robot offers superior, precise performance.

Specs

Reach
2035 mm
Axes
6
Repeatability
0.5 mm
Mass
370 kg
Structure
Articulated
Mounting
Floor, Inverted, Angle

Motion Range

J1
±90°
J2
±100°
J3
+5° - 163°
J4
±260°
J5
±140°
J6
±260°
